Submersible pump DG Blue
cast iron Electromechanical assembly in EN-GJL-250, for submerged operation, complete with nr. 2 mechanical seals, a silicon carbide and graphite alumina, installed in the oil chamber and V-ring in direct contact with the liquid. Ecological dry motor. hydraulic body in monolithic casting with motor casing.
Used with soiled biological wastewaters and sewage liquids. Suitable and reliable for domestic use and residential use.
construction materials
- motor casing: Cast iron EN-GJL 250
- Impeller: Technopolymer
- Screws: Stainless Steel - Class A2-70
- Standard gasket: Rubber - NBR
- Motor shaft: Stainless steel - AISI 420
- Painting: Epoxy two-component water-based (average thickness 80 uM)
- Standard mechanical seals: A mechanical seal in silicon carbide (SiC) and a mechanical seal in alumina graphite (AL), V-ring
Operating limits
- Maximum operating temperature: 40 ° C
- PH of treated liquid: 6 ÷ 14
- the treated liquid viscosity: 1 mm2 / s
- Maximum immersion depth: 20 m
- the treated liquid density: 1 Kg / dm3
- maximum sound pressure: 70 dB
- Max starts per hour: 30
Disponibile diverse potenze nel menù:
Scheda tecnica del prodotto CLICCA QUI
|
Modello
|
Potenza
|
Qm3/h
|
0
|
3.6
|
7.2
|
10.8
|
14.4
|
18
|
21.6
|
25.2
|
|
Monofase
|
kW
|
HP
|
QL/min
|
0
|
60
|
120
|
180
|
240
|
300
|
360
|
420
|
|
PA0600
|
0.55
|
0.75
|
H (mt)
|
10.1
|
9.5
|
8.5
|
7.2
|
5.7
|
4.2
|
2.6
|
/
|
|
PA0605
|
0.75
|
1.00
|
11.6
|
11.2
|
10.2
|
9.1
|
7.6
|
6.0
|
4.3
|
2.7
|
|
PA0610
|
1.10
|
1.50
|
12.3 |
11.6 |
10.7 |
9.6 |
8.6 |
7.3 |
6.1 |
4.9 |
